Adapter
-
-
Hard disk controller for Big Box Amiga’s
Untested, but very likely to work. Worth the money for the chips alone.
€40,00 -
Harlequin 32bit Framebuffer – Extremely Rare!
Comes with box, manuals and software.
CompanyKeybonus Ltd. / Amiga Centre Scotland, UK
Date1991
AmigaA2000, A3000, A4000
InterfaceZorro II
Autoconfig ID2118 / 100
framebuffer
- the Amiga’s first 24 bit display device
- designed to provide compatibility with genlocks, single frame controllers and other video equipment
- 24 bit display7 and realtime animation
- the output of the Harlequin is totally independent from the Amiga video
- multiple Harlequin boards can be installed in one Amiga, each driving a separate device and outputting a different image
- optional 8 bit alpha channel – superimpose high quality graphics onto live signal, or smoothly blend paint images
- optional double buffering – two 24 bit displays instantly available
- screen modes:
- 740Ă—486, 832Ă—486, 910Ă—486 (NTSC, 60 Hz)
- 740Ă—576, 832Ă—576, 910Ă—576 (PAL, 50 Hz)
- 4, 8, 15 and 24 bit colour depth
- 15 kHz interlaced or 31 kHz non-interlaced in all resolutions
- models:
- H1500 1.5 MB VRAM
- H2000 2 MB VRAM – alpha channel
- H3000 3 MB VRAM – double buffering
- H4000 4 MB VRAM – alpha channel + double buffering
- all models can be upgraded to later ones
- outputs (two DB15 connectors):
- RGB + Composite sync
- digital key output
- alpha channel
- genlock control lines
- sandwich card, it occupies the space of two Zorro slots
- separate PAL and NTSC versions
€395,00 -
LumaFix 64
- LumaFix 64
- Tested and tuned
LumaFix64 was made to easily remove vertical lines from your Commodore 64 image caused by signals also in the VIC-II video chip. It also has an adjustment for the Chroma signal that can help reduce problems related mostly to s-video connection on modern TVs – the dreaded checkered pattern.
LumaFix64 helps getting rid of the problem by inverting the interfering signals and feeding it back into the Luma signal.
€15,00 -
MacroSystem Vlab Video Digitizer External
Comes without any cabling. However, this is one of the best video digitizers out there!
€20,00 -
-
-
Scala Echo EE100
Control your video recorder or other IR machines with Scala
€20,00
